Drawing-based custom fabrication of fused quartz, sapphire, and technical ceramic components — from prototype to production, any geometry, any specification.
Custom dimensions and specifications available upon request.
Custom Precision Parts
Tuguan Semiconductor’s core business is drawing-based custom fabrication. Most semiconductor process components are application-specific — we manufacture to your engineering drawings, CAD files, or physical samples.
How to Order Custom Parts
Option A — Engineering Drawing
Submit a 2D drawing (PDF, DWG, DXF) with:
- All critical dimensions and tolerances
- Surface finish requirements (Ra or equivalent)
- Material specification (grade, purity)
- Any special requirements (He leak test, XRD, ICP-OES)
We will review within 1 business day and issue a quotation with lead time.
Option B — CAD File (3D Model)
Submit a STEP or IGES 3D model. Our engineers extract a 2D working drawing for your approval before production begins.
Option C — Reverse Engineering (Physical Sample)
Send a worn or broken component for measurement. We will:
- Measure all dimensions using CMM and profilometer
- Identify material by XRF or visual inspection
- Generate a 2D drawing for your approval
- Manufacture exact replacements
Design for Manufacturability Support
Our application engineers can advise on:
| Topic | Guidance |
|---|---|
| Tolerance assignment | Which tolerances are achievable vs. unnecessarily tight |
| Wall thickness minimums | Structural limits for drilling and thin-wall sections |
| Corner radii | Minimum achievable internal radii |
| Surface finish requirements | What Ra is actually needed for each surface |
| Material selection | Which grade offers the best performance/cost trade-off |
This service is free — we prefer to get the design right before production begins.
Capabilities Summary
| Process | Materials | Tolerance |
|---|---|---|
| CNC cylindrical grinding | All | ±0.01 mm |
| Surface grinding + lapping | All | ±0.005 mm / flatness < 0.5 μm |
| Optical polishing | Quartz, sapphire | Ra < 0.1 nm |
| Diamond drilling | All | ±0.01 mm diameter |
| Diamond slotting | All | ±0.02 mm |
| Precision cutting (wire saw) | All | ±0.02 mm |
| Fusion welding | Quartz | He leak < 1×10⁻⁹ mbar·L/s |
| Flame forming | Quartz | Profile ±0.5 mm |
| Annealing | Quartz | Birefringence < 5 nm/cm |
Lead Times
| Order Type | Typical Lead Time |
|---|---|
| Prototype (1–5 pieces, moderate complexity) | 5–10 working days |
| Small batch (6–50 pieces, standard geometry) | 8–15 working days |
| Production run (50–500 pieces) | 15–25 working days |
| Complex multi-step / tight tolerance | 15–30 working days |
| Rush (subject to capacity) | Contact us |
Quality Documentation
All custom parts ship with:
- Dimensional inspection report (CMM)
- Material certificate
- Certificate of Conformance (ISO 9001)
- Any additional QC specified at order placement
Ready to order or need a custom size?
Submit your drawing or specifications — we respond within 24 hours.
